RMT 0010 Pump Spare Parts


Valve (3/4" male)
RMT Part#
0010 01
Ref Part #
R137313

Valve (3/4" male)
Ring - Retainer
RMT Part#
0010 02
Ref Part #
C090746

Ring - Retainer
Filter - Screen
RMT Part#
0010 03
Ref Part#
C078057

Filter - Screen
Air inlet bushing
RMT Part#
0010 04
Ref Part #
C113782

Air inlet bushing
O-ring
RMT Part#
0010 05
Ref Part #
C046471

O-ring
Housing - Governor
RMT Part#
0010 06
Ref Part #
C113799

Housing - Governor
Plug - Oil
RMT Part#
0010 07
Ref Part #
C085233

Plug - Oil
O-ring
RMT Part#
0010 08
Ref Part #
A082777

O-ring
Screw - Cap (Allen)
RMT Part#
0010 09
Ref Part #
C064806

Screw - Cap (Allen)

Lock washer (1/4")
RMT Part#
0010 10
Ref Part #
C012058

Lock washer (1/4")
Wick
RMT Part#
0010 11
Ref Part #
C113787

Wick
Plug - Orifice
RMT Part#
0010 12
Ref Part #
C113789

Plug - Orifice
Gasket - Housing
RMT Part#
0010 13
Ref Part #
C113791

Gasket - Housing
Ring - Retainer
RMT Part#
0010 14
Ref Part #
S087190

Ring - Retainer
Retainer - Spring
RMT Part#
0010 15
Ref Part #
C113780

Retainer - Spring
Spring - Compression
RMT Part#
0010 16
Ref Part #
C113779

Spring - Compression
Valve - Governor
RMT Part#
0010 17
Ref Part #
C090935

Valve - Governor
Pin - Governor valve
RMT Part#
0010 18
Ref Part #
C084364

Pin - Governor valve
Cage - Governor
RMT Part#
0010 19
Ref Part #
C113798

Cage - Governor
Governor body complete
RMT Part#
0010 20
Ref Part #
Z8769462

Governor body complete
Pin - Governor weight
RMT Part#
0010 21
Ref Part #
-

Pin - Governor weight
Button - Push pin
RMT Part#
0010 22
Ref Part #
-

Button - Push pin
Ring - Retaining
RMT Part#
0010 23
Ref Part #
-

Ring - Retaining
Pin - Governor push
RMT Part#
0010 24
Ref Part #
-

Pin - Governor push
Weight - Governor
RMT Part#
0010 25
Ref Part #
-

Weight - Governor
Body - Governor
RMT Part#
0010 26
Ref Part #
-

Body - Governor
Retainer - Pin
RMT Part#
0010 27
Ref Part #
-

Retainer - Pin
Bearing - Ball
RMT Part#
0010 28
Ref Part #
S014490

Bearing - Ball
Washer - Tension
RMT Part#
0010 29
Ref Part #
C089794

Washer - Tension
Shim - Motor
RMT Part#
0010 30
Ref Part #
C113786

Shim - Motor
End plate - Upper
RMT Part#
0010 31
Ref Part #
C089790

End plate - Upper
Rotor complete
RMT Part#
0010 32
Ref Part#
Z8770462

Rotor complete
Sleeve - Rotor
RMT Part#
0010 33
Ref Part #
C089779

Sleeve - Rotor
Body - Rotor
RMT Part#
0010 34
Ref Part #
-

Body - Rotor
Blade - Rotor
RMT Part#
0010 35
Ref Part #
C092050

Blade - Rotor
Shaft - Rotor
RMT Part#
0010 36
Ref Part #
C113797

Shaft - Rotor
Pin - Roll
RMT Part#
0010 37
Ref Part #
P056138

Pin - Roll
Liner - Motor
RMT Part#
0010 38
Ref Part #
C092047

Liner - Motor
Pin - Roll
RMT Part#
0010 39
Ref Part #
C088617

Pin - Roll
Plate - Lower end
RMT Part#
0010 40
Ref Part #
C113795

Plate - Lower end
Bearing ball
RMT Part#
0010 41
Ref Part #
S039951

Bearing ball
Housing - motor
RMT Part#
0010 42
Ref Part #
-

Housing - motor
Plug - Pipe (1/8")
RMT Part#
0010 43
Ref Part #
C035390

Plug - Pipe (1/8")
Screw cap
RMT Part#
0010 44
Ref Part #
P070423

Screw cap
Lock washer
RMT Part#
0010 45
Ref Part #
C011005

Lock washer
O Ring
RMT Part#
0010 46
Ref Part #
CA087468

O Ring
Seal - Shaft
RMT Part#
0010 47
Ref Part #
C113792

Seal - Shaft
Plate - Wear (Upper)
RMT Part#
0010 48
Ref Part #
C113783

Plate - Wear (Upper)
Screw - Flat head
RMT Part#
0010 49
Ref Part #
C113793

Screw - Flat head
Sleeve - Impeller
RMT Part#
0010 50
Ref Part #
C113790

Sleeve - Impeller
Impeller - Pump
RMT Part#
0010 51
Ref Part #
F814673

Impeller - Pump
Spacer (Retaining)
RMT Part#
0010 52
Ref Part #
C113785

Spacer (Retaining)
Bolt - Hex. (Long lok)
RMT Part#
0010 53
Ref Part #
C113788

Bolt - Hex. (Long lok)
Plate - Wear (Lower)
RMT Part#
0010 54
Ref Part #
F814672

Plate - Wear (Lower)
Shim (Wear plate)
RMT Part#
0010 55
Ref Part #
C115755

Shim (Wear plate)
Shim (Wear plate)
RMT Part#
0010 56
Ref Part #
F814688

Shim (Wear plate)
Impeller housing complete
RMT Part#
0010 57
Ref Part #
-

Impeller housing complete
Housing - Pump
RMT Part#
0010 58
Ref Part #
-

Housing - Pump
Screen - Sump
RMT Part#
0010 59
Ref Part #
C113794

Screen - Sump
Nipple - Outlet
RMT Part#
0010 60
Ref Part #
R137579

Nipple - Outlet
Handle - Pump
RMT Part#
0010 61
Ref Part #
C085347

Handle - Pump
Pipe - Exhaust
RMT Part#
0010 62
Ref Part #
Pipe - Exhaust (1" NPT 1" BSP)

Pipe - Exhaust
Pipe - Exhaust (NPTF)
RMT Part#
0010 63
Ref Part #
S038723

Pipe - Exhaust (NPTF)
