| RMT Part # | Reference Part # | Shank (Hex) | Taper | Length | ||
|---|---|---|---|---|---|---|
| mm | Inch | degree | mm | Inch | ||
| TR11 - 1220 - 6112 TR11 - 1525 - 0115 TR11 - 1830 - 6118 TR11 - 1980 - 6120 TR11 - 2440 - 6124 TR11 - 3050 - 6131 |
7876 - 6112 - 11 579 - 0115 - 11 7876 - 6118 - 11 7876 - 6120 - 11 7876 - 6124 - 11 7876 - 6131 - 11 |
22 x 108 | 7/8" x 4¼" | 11° | 1220 1525 1830 1980 2440 3050 |
4" 5" 6" 6’ 6” 8" 10" |
| TR12 - 610 - 6106 TR12 - 1220 - 6112 TR12 - 1830 - 6118 TR12 - 1980 - 6120 TR12 - 2440 - 6124 TR12 - 3660 - 6137 |
7870 - 6106 - 12 7870 - 6112 - 12 7870 - 6118 - 12 7870 - 6120 - 12 7870 - 6124 - 12 7870 - 6137 - 12 |
22 x 108 | 7/8" x 4¼" | 12° | 610 1220 1830 1980 2440 3660 |
2" 4" 6" 6’ 6" 8" 12" |
| TR7 - 610 TR7 - 1220 TR7 - 1830 TR7 - 1980 TR7 - 2440 TR7 -3050 TR7 - 3660 |
- - - - 7888 - 6124 - 07 - - |
22 x 108 | 7/8" x 4¼" | 7° | 610 1220 1830 1980 2440 3050 3660 |
2" 4" 6" 6’ 6" 8" 12" |
