Pneumatic Column Bar / Jack


3175 1357 80 M
Pneumatic Column Bar / Jack
Pneumatic Column Bar / Jack

Technical Specification

Description Ref Part # EV #
Pneumatic Column Bar SJ 0020 -
Cylinder Guide Nut SJ 0021 1
Oil Seal SJ 0022 2
Circlip SJ 0023 3
Cylinder SJ 0024 4
Piston Rod SJ 0025 5
Bucket Washer Steel SJ 0026 6
PU Bucket SJ 0027 7
Nut SJ 0028 8
Pin SJ 0029 9
