Technical Specification
| Description | Ref Part # | EV # |
| Beam Complete (1 - 5) | 3142 0160 80 M | A |
| Beam With Screw (Steel Casting) | 3142 0160 00 M | 1 |
| Screw | 0147 1404 00 | 2 |
| Nut | 3142 0163 00 | 3 |
| Guide Rail | 3142 0231 00 | 4 |
| Lock Washer | 0333 3137 00 | 5 |
| Feed Screw Complete (6,8,18,19 & B1) | 3142 0165 80 M | B |
| Feed Screw Complete With Castle Nut | 3142 0165 00 | 1 |
| Spiral Pin | 3142 0463 00 | 8 |
| Gear Wheel | 3142 0178 00 M | 18 |
| Nut | 3142 0179 00 M | 19 |
| Bearing Casing Bottom Complete - Motor Side (7,9 - 17,72) | SJ 0001 M | B1 |
| Split Pin | 3142 0462 00 M | 7 |
| Spacer Sleeve | 3142 0168 00 M | 9 |
| Seal Ring | 3142 0169 00 | 10 |
| Cover | 3142 0777 00 M | 11 |
| Oil Seal | 0666 2263 00 M | 12 |
| Ball Bearing | 0502 1106 00 M | 13 |
| Spacer Ring (8 mm) | 3142 0175 00 M | 14 |
| Thrust Bearing | 0511 0106 00 M | 15 |
| Spacer Sleeve | 3142 0176 00 M | 16 |
| Bushing | 3142 0760 00 M | 17 |
| Spacer Ring (9 mm) | 3142 0175 00 M | 72 |
