Technical Specification
| Model # | CP 4123 2H/2R | CP 4123 3H/3R | CP 4123 4H/4R |
| Weight | 7 kg (15 lb) | 8 kg (17.65 lb) | 8.65 kg (19 lb) |
| Length | 375 mm (14.8") | 426 mm (16.75") | 460 mm (18.1") |
| Blows per minute | 2500 | 2050 | 1600 |
| Piston stroke | 50.8 mm (2") | 76.2 mm (3") | 101.6 mm (4") |
| Air pressure | 6.2 bar (90 PSI) | ||
| Air consumption | 14 l/s (30 cfm) | ||
| Piston dia | 28.6 mm (1.13") | ||
| Air inlet (Standard) | 9.5 mm (⅜") BSP | ||
| Air inlet (Optional) | 9.5 mm (⅜") NPT | ||
| Retainer type | Spring | ||
| Shank | Hex 14.7 mm (0.580") | Round 17.3 mm (0.680") | ||
| Ref. Part # (Hex 0.580") | 8900 0001 05 | 8900 0001 07 | 8900 0001 09 |
| Ref. Part # (Rd 0.680") | 8900 0001 04 | 8900 0001 06 | 8900 0001 08 |
| Manufacturer | OEM | ||
